AMT Pangaea CP-16M-EB (EVALUATION BOARD)
AMT Pangaea CP-16M-EB (EVALUATION BOARD)
SKU:CP-16M-EB
Couldn't load pickup availability
INTRODUCTION
As you may know, AMT Electronics productions the AMT Pangaea CP-16M (module).
The AMT CP-16M — is a built-in digital audio processing module with preinstalled software. AMT Pangaea CP-16 module is designed especially for those who create all sorts of guitar devices: power amplifiers, preamplifiers, guitar effects etc.
The CP-16 module is so small that it can easily be integrated into any compact devices, such as «newfangled» mini effect pedals.
IMPORTANT NOTE! To apply the module, the user must have some basic knowledge in the field of electronics and possess some computer literacy. More detailed technical information on the module AMT Pangaea CP-16M you'll find on the product's page at the AMT Media Center: https://media.amtelectronics.com/amt-pangaea-cp-16-module/
► ABOUT THE CP-16M-EB (EVALUATION BOARD)
To make the process of getting to know easier and shorten the development time of the final product, AMT Electronics has developed a special AMT Pangaea CP-16M-EB Evaluation Board.
The board has all the necessary interfaces for quickly starting the work with the module. The user can use some circuit designs of the evaluation board for the use in his final product. Many connectors of the evaluation board are duplicated by additional connecting contacts, which can be used by the developer to move the necessary connectors to the locations determined by the final design of the user’s device.
That is, in cases where the developer does not need to make many instances of the device. When not constrained by the size of the final design, he can apply the ready AMT Pangaea CP-16M-EB board, possibly making some changes to the circuit.
► TECHNICAL PARAMETERS
- Supply voltage: 9-12V DC
- Consumption current: 9V DC → 120 мА / 12V DC → 100 мА
- Power supply as well as the AMT Pangaea CP-16M (module) are not included!
► USER'S GUIDE
All other necessary information about the device (User’s Guide, videos, etc.) you'll find on the product's page at the AMT Media Center:
https://media.amtelectronics.com/amt-pangaea-cp-16m-eb/
💡 FOR THIS DEVICE, YOU MAY NEED TO PURCHASE
Noiseless power supply is purchased separately (you can choose):
|
AMT DC 12V, 1.25А AC/DC —
|
AMT DC 9V, 1.5А AC/DC —
|
IMPORTANT NOTE ABOUT THE POWER SUPPLY
For powering the AMT devices always use specialized power supplies originally designed for guitar pedals & gear meeting the following basic requirements:
Please, don't try to use for these purposes the usual cheapest power supply from household appliances and electronics, like from your laptop, Wi-Fi router, etc.! Such power supplies have a reverse polarity compared to AMT devices, so it won't work! Even if you're «the guy was born with a soldering iron in the hand» and almost ready to change a polarity of such power supply — we strongly not recommend you do that!
Those kinds of power supplies are not intended for using with the guitar gear. Otherwise, you'll get a problematic very noisy guitar sound full of «hum», «cheep», and other sound «effects»!
