AMT SY-1 Stutterfly — HQ Digital Delay
AMT SY-1 Stutterfly — HQ Digital Delay
SKU:SY-1
Couldn't load pickup availability
ABOUT THE PRODUCT
Stut, stut, stut, stut, .... STUTTERFLY!
AMT Electronics SY-1 has all the features of a delay pedal that modern guitarists are looking for, all in a small compact enclosure that will fit easily on any pedalboard.
Most delays include the standard time, feedback, and level controls. AMT recognized the need for a few extra options that would greatly improve the versatility and flexibility of the pedal. The Stutterfly delay also includes an added TONE control, MIX feature, and MOD adjustment; usually only found on more expensive/larger sized units.
Sounds great with both clean and overdrive distorted guitar signals.
► INTRODUCTION
The unit is based upon the high-quality DSP providing wide dynamic range of the device. The original circuitry design developed by АМТ experts resulted in insignificant current consumption (less than 36mА). The refusal from operational amplifiers traditionally used in similar devices in favor of JFET has dramatically enhanced the pedal's sound.
The device features passive bypass which on one hand requires high-quality cables but on the other hand retains the original instrument sound when the effect is off.
► CONTROLS
- LEVEL controls the overall level output of the pedal.
- TIME controls the length of the time in between delay repeats. Maximum delay time is 1 second.
- FB FEEDBACK adjusts the number of repeats that are played back.
- MIX control allows the user to blend the original dry signal with the reverb wet signal. A must have feature for getting that perfect mix.
- TONE knob allows the user to adjust the overall tone of the delayed signal. This does NOT affect the overall output signal, only the repeats. Achieve and replicate any style of delay from warm analog, creamy tape, to brighter tighter delays as well.
- MOD is a feature allowing the addition of modulation into the delayed repeats. This feature can also be bypassed by rotating it entirely left. Add a hint of tape modulation, wobble, or chorus type effect to the delay.
► FEATURES
- TRUE BYPASS circuitry for no tone coloration when off
- DSP powered for the cleanest delay available
- Delay sweep from 30 milliseconds up to 1 second
- High quality components
- Film capacitors
- Small and compact size
► TECHNICAL PARAMETERS
- Input resistance: 1 МОhm
- Response: Nom. -10dB (250mV) Max. +4dB (1V)
- Output resistance: 1 kОhm
- Output level: Max. +8dB (2V)
- Weight: 280 g.
- Dimensions: 114 mm x 74 mm x 55 mm
- Supply voltage: 9-12V DC
- Battery Power: 1 x 6F22 battery (9v)
- Consumption current:
- 36 mA (at 9V)
- 30 mА (at 12V)
- The power supply is not included!
► USER'S GUIDE
All other necessary information about the device (User’s Guide, videos, etc.) you'll find on the product's page at the AMT Media Center:
https://media.amtelectronics.com/amt-sy-1/
💡 FOR THIS DEVICE, YOU MAY NEED TO PURCHASE
Noiseless power supply is purchased separately (you can choose):
|
AMT DC 12V, 1.25А AC/DC —
|
AMT DC 9V, 1.5А AC/DC —
|
IMPORTANT NOTE ABOUT THE POWER SUPPLY
For powering the AMT devices always use specialized power supplies originally designed for guitar pedals & gear meeting the following basic requirements:
Please, don't try to use for these purposes the usual cheapest power supply from household appliances and electronics, like from your laptop, Wi-Fi router, etc.! Such power supplies have a reverse polarity compared to AMT devices, so it won't work! Even if you're «the guy was born with a soldering iron in the hand» and almost ready to change a polarity of such power supply — we strongly not recommend you do that!
Those kinds of power supplies are not intended for using with the guitar gear. Otherwise, you'll get a problematic very noisy guitar sound full of «hum», «cheep», and other sound «effects»!
