AMT Incinerator NG-1 — noise gate pedal
AMT Incinerator NG-1 — noise gate pedal
SKU:NG-1
Couldn't load pickup availability
ABOUT THE PRODUCT
The device IS NOT a copy of any known device. AMT engineers used their own technical ideas and their own approaches to solving the problem of noise suppression of the guitar signal.
► INTRODUCTION
AMT NG-1 is a device to eliminate noises in the guitar signal chain.
The device is effective and easy to use.
► FEATURES
- Small dimensions (Snickers-size).
- Minimum of controls.
The main element of control is «Threshold» knob that defines the level at which the noise suppression is On. Quick reaction to the appearance of the guitar signal and automatic decay time control allows to eliminate harmonic distortion and quickly switch to a «cut-off» mode when the guitar signal disappears.
- A choice of bypass mode: active bypass or signal’s complete «cut-off».
- A loop for connecting FX-drive pedals, preamps, etc.
When an FX-drive pedal or a preamp is placed in the loop, the level detector of the NG-1 gets the signal directly from the guitar and the controlled attenuator stands after the pedal or preamp output. Thus, the threshold of noise reduction is set once and is effective for any channel of the device in the loop.
► NOTES
- In case of use of spatial (time) effects in a guitar path with the noise suppression device (NG-1), it is recommended to place them after the NG-1, to prevent cutting of reverberation «tails».
- If effective noise reduction is observed at the position of the knob THRESHOLD more than 12-13 hours, you should first pay attention to the shielding of the guitar and the grounding of the equipment, and then use the noise reduction device NG-1.
► TECHNICAL SPECIFICATION
| 🎼 This device is for: | guitar / bass guitar |
| 📦 Package's included: |
|
| 🔌 Cables are included: | ❌ |
| ⚠️ Device's body material: | metal (steel) |
| 🔋 Powered by a 9V 6F22 battery: | ❌ |
| 🔋 Batteries are included: | ❌ |
| 💡 Input consumption current (mA): | 12 |
| ⚡️ Powered by a power supply: | ✅ |
| ⚡️ Power supply type: | DC adapter |
| ⚡️ Range of operating voltage (V): | 12 (strongly!) |
| ⚡️ Power supply connector's type: | Male DC 5,5mm x 2,1mm |
| ⚡️ The polarity of the power supply connector: | «-» is inside «+» is outside
|
| ⚡️ Power supply is included: | ❌ |
| ⚡️ Recommended power supply (clickable): |
|
| 📏 Dimensions of the device: | 94 x 64 x 56 mm |
| ⚖️ Weight of the device: | 183 g. |
| 💻 URL Link to the AMT official website: | 💢LINK💢 |
► USER'S GUIDE
All other necessary information about the device (User’s Guide, videos, etc.) you'll find on the product's page at the AMT Media Center:
https://media.amtelectronics.com/amt-incinerator-ng-1/
💡 FOR THIS DEVICE, YOU MAY NEED TO PURCHASE
Noiseless power supply is purchased separately (DC 12V ONLY!):
|
AMT DC 12V, 1.25А AC/DC —
|
IMPORTANT NOTE ABOUT THE POWER SUPPLY
For powering the AMT devices always use specialized power supplies originally designed for guitar pedals & gear meeting the following basic requirements:
Please, don't try to use for these purposes the usual cheapest power supply from household appliances and electronics, like from your laptop, Wi-Fi router, etc.! Such power supplies have a reverse polarity compared to AMT devices, so it won't work! Even if you're «the guy was born with a soldering iron in the hand» and almost ready to change a polarity of such power supply — we strongly not recommend you do that!
Those kinds of power supplies are not intended for using with the guitar gear. Otherwise, you'll get a problematic very noisy guitar sound full of «hum», «cheep», and other sound «effects»!
